Moulding Knives For The Shop Fox And
Williams And Hussey Moulders Are Our
Large new profile catalog. Many profiles
We Accept PayPal for your convenience.
(just ask us for a PayPal invoice to be
emailed to you).
Overnight Shipping For 20.00 is now
available to most areas. Price applies to
one or two sets of knives. Additional
shipping costs apply for 3 or more sets
We have had several requests for a
Custom Moulding Knives Facebook page
but unfortunately we have been too busy
to establish or maintain one. We have
been busy focusing all our concentration
on knife making and filling orders. We do
plan to establish a Facebook page in the
future so please check back.
We offer you the option of corrugated
W&H knives. These would give you the
opportunity to also use them in your
W&H or Shop Fox and some shaper
applications as well as many types of
moulders. Cost is 20.00 per inch of steel.
Only the M2 grade is available
CMK is open for phone calls between the
hours of 8AM and 5:30PM Eastern Time
Monday - Friday. Feel free to call
(802)753-7105 or email any time:
We offer the higher grade Black Nitride
in corrugated steel for the Woodmaster
700S2 Molding Head and also multi
spindle moulders such as Weinig, Price
is 23.00 per inch of steel.
|Jet, Powermatic, Grizzly, RBI, Belsaw, Woodmaster and Craftsman
moulder owners please read the following:
If you are in need of a set of 3 smooth knives 1/4" thick we can help
you, but we do not supply gibs.
If you are interested in purchasing a single knife set then please
click the "Single Knives" link below and mention that CMK sent you:
Fast turnaround time, usually 24-48 hours from time order is
received. Current lead time will be displayed at the top of this page*.
Please email or call with any questions.
Just click "Contact Us" if you have any questions or comments.
Thanks for checking us out.
68 Grove Rd.
Shaftsbury, VT 05262
Phone: (802) 753-7105 8AM - 5:30PM EST
Fax Anytime:(802) 419-4872
* Current lead time is an estimate and may change
without notice but will be updated from time to time.
We strive to get all orders processed in a timely manner.
This allows us to make templates in
house which cuts lead time to a
minimum and also keep costs low.
We also sell templates to those of
you who choose to grind your own
knives. Just another way that Catalog
Moulding Knives is striving to meet
your knife grinding needs.
|Attention Williams & Hussey And Shop Fox Owners:
Black Nitride Steel
We are proud to offer Black Nitride steel.
HSS Black Nitride Steel offers up to 100% longer run times than the industry
standard M2-HSS for only 20% more in cost.
Black Nitride is HSS that is case hardened with pure carbon about .015 deep
and ranges from 72 Hrc at the surface to 63 Hrc .020 deep in the steel. The
steel is then coated with Black Oxide (like gun bluing) to reduce pitch build
up and eliminate rust.
This will be a great alternative to M2 steel for all those who require a steel
harder than M2 but do not want to spend a fortune for it.
Price for this incredible steel starts at just 23.50 per inch of steel.
Currently Available: 4 Choices Of Steel Hardness:
Need Carbides? Milling MDF? Click Here.
Black Nitride (High Grade)- From 23.50 per inch of steel needed.
For a cost of only 20% more than the M2 steel you get a steel that has 100%
longer run times. Most value for the money!!
This is the best all around steel we have ever made knives from (customer
favorite, please see description down below price chart). We offer it in both
Williams and Hussey (and Shop Fox) and corrugated steel for the Woodmaster
Molding Head and for larger molders as well.
M2 HSS (Quality Grade)- From 19.50 per inch of steel needed.
M2 steel is our premium HSS. It is great for longer runs in both softwoods and
hardwoods. For even longer runs in hardwoods and exotic woods see Black
V2 HSS (Economy Grade)- From 17.50 per inch of steel needed.
V2 steel is the latest in HSS technology. It is great for long runs of softwoods and
medium runs of hardwoods.
Endurance +SR Coated (Highest Grade)- Please ask for quote.
For W&H and Shop Fox only.
Our new "Endurance" super run moulder steel is the best option for extended
production time and tool life. An excellent choice for cutting problem hardwoods
and Lightweight MDF and for super long productions runs. Tool life is increased
up to 600 percent over normal High Speed Steel without the inconvenience
associated with using carbide knives. This proprietary knife coating process
uses the latest technology developed in Europe for metal working tools. An ion
sputtering magnetron chamber applies a P.V.D. (Physical Vapor Deposit); 5 layer
film of Titanium, Ceramic crystals and other elements to the knife surface to form
an "extremely hard and heat resistant cutting edge".
New Products And News From CMK:
|Depth Of Cut
|Up To 7/16"
|Up To 11/16"
|3/4" Or More
Price per inch of steel for W&H,
Shop Fox, and 5/16" Corrugated:
|Services We Provide:
At Custom Moulding Knives our knives are precision ground on state
of the art equipment in order to get you the best results possible.
Knives are ground in sets of 2 and are balanced to within .1 gram of
each other in weight.
Modifications of profiles are allowed but at an additional cost of 20.00
per profile. By modifications we mean changing an overall size or
perhaps adding a bead or flute. If changing the size results in the
need of using larger knife blanks then an additional fee will result. If
the profile is modified smaller then smaller blanks may be required,
thus reducing the cost.
Templates (3/16" Acrylic) for our catalog profiles may be purchased at a
cost of 20.00 each. Templates are needed in order to sharpen the
knives, and are very handy to have in case you ever sell or give away
To Place An Order please call or email us. Eventually this website will
have a shopping cart and you will be able to pay right on the site. We
accept all credit cards and PayPal also. To use PayPal just request us
to email you an invoice.
CAD Drawings will be supplied upon request. That will enable you to
see the detail up close before we make the actual knives.
|We Sell Moulding Knives For The Following Machines ONLY:
Shop Fox, Williams And Hussey, Woodmaster (corrugated only for 8"
Molding Head), Weinig and most other multi spindle moulders, and for
shaper cutterheads that fit 5/16" corrugated steel. If your machine is
not listed then please inquire anyway so that we may forward you to a
reliable source for knives.
Please ask for
|LIMITED TIME: Free 2 Day
Shipping For Any Profiles In Our
Vast Profile Catalog. No Limit.
Please mention Free Shipping. Orders shipped to U.S. addresses only
